Fully automatic 2- end terminal crimping machine

Short Description:

SA-ST100 Suitable for 18AWG~30AWG wire ,is Fully automatic 2 end terminal crimping machine ,18AWG~30AWG wire use 2- wheel feeding , 14AWG~24AWG wire use 4-Wheel feeding,Cutting length is 40mm~9900mm ( Customizable) , Machine with English color screen is very easy operate.Crimping Doube end at one time , it’s Improved wire process speed and save labor cost.

Send email to us

Product Detail

Product Tags

Product Video

Product Introduction

Advantage

1. Micro-computer controlled system, high accuracy wire cutting stripping crimping.
2. Wire cutting, stripping Twisting and crimping are completed one time.
3. English LCD screen easy operation.
4. Different terminal and different applicator , it uses stuck-type mould, and it is easy and convenient to disassemble.

Products Parameter

Model	SA-ST100
Name	Automatic double wire cutting stripping terminal crimping machine
Display	Color LCD touch screen
Blade adjustment method	Motorized adjusting
Wire cutting length	45mm-9999mm
Cutting tolerance	0.20%
Wire crimping length	1.5-10mm
Suitable wires	AWG18—28#( Other can customized )
cutting speed	1500-4000PCS/hour
Crirmp force	standard 2.0T(customized available)
Power	AC 220V
Rated power	2.5KW
Weight	320kgs
Size	1600L800W600H
