Pneumatic outer jacket Cable Stripping Machine – Sanao Featured Image
  • Pneumatic outer jacket Cable Stripping Machine – Sanao
  • Pneumatic outer jacket Cable Stripping Machine – Sanao
  • Pneumatic outer jacket Cable Stripping Machine – Sanao

Pneumatic outer jacket Cable Stripping Machine – Sanao

Short Description:


Product Detail

Product Tags

Related Video

Feedback (2)

Well-run gear, qualified revenue workforce, and superior after-sales companies; We've been also a unified huge loved ones, anyone persist with the organization benefit "unification, determination, tolerance" for Single End Terminal Crimping And Tinning Machine , Rotary Angle Tape Cutting Machine , Wire Label Printing And Labeling Machine , We are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more detail!
Pneumatic outer jacket Cable Stripping Machine – Sanao Detail:

Product Video

Product Introduction

Rocessing wire range: Max.15MM Outer diameter ans stripping length Max. 100mm,SA-310 is Pneumatic wire stripping machine that Stripping outer jacket of sheathed wire or single wire , It is controlled by foot switch and stripping length is adjustable. It has the characteristics of simple operation and fast stripping speed, It’s Greatly Improved stripping speed and save labor cost.

Wire stripping machine picture

Advantage

1. This machine is mainly used for stripping multi-conductor computer cables, telephone cables, parallel cables and power cords.
2. The machine is based on the standard version to use dual cylinders, adding the delay function after the peeling. The thread is twisted for 1 second, the effect is more stable and the quality is more perfect.
3. Exquisite and compact design, small foot pedal
4. Air pressure operation and electromagnetism value control
5. Changing procedure & materials rapidly
6. High-efficiency step drive, high-accuracy and fast speed

Products Parameter

Model

SA-305

SA-310

SA-315

SA-330

SA-416

Wire Dia

Max 5mm

Max 15mm

Max 20mm

Max 20mm

Max 30mm

Stripping Length

Max 50mm

Max 100mm

Max 150mm

Max 330mm

Max 150mm

Force

31-37kg

49-115kg

84-196kg

84-196kg

165-300kg

Cylinder Dia

40mm

50mm

50mm

50mm

80mm

Air Connection

3-7kg/cm2

Power Supply

110/220VAC, 50/60Hz

Weight

20kg

25kg

35kg

65kg

50kg

Dimensions

40*30*27cm

48*33*28cm

66*39*34cm

110*55*45cm

61.5*42.5*37.5cm
Product detail pictures:

Pneumatic outer jacket Cable Stripping Machine – Sanao detail pictures

Pneumatic outer jacket Cable Stripping Machine – Sanao detail pictures

Pneumatic outer jacket Cable Stripping Machine – Sanao detail pictures
